Air2-QDT600W
Wireless dual technology curtain detector with anti-masking function
The Air2-QDT600W detector from the QTech product line is designed to meet the protection and security needs of indoor environments and provides the ease of installation typical of wireless alarm systems.
Dual infrared and microwave technology with 3m coverage range and 70° angle, accurate digital analysis and identification of the direction of the person crossing the path: Air2-QDT600W has highly advanced features to ensure maximum detection reliability.
In installations covering gates or access points such as doors and windows, the anti-masking function protects the device from attempts at masking to which it is exposed, making it particularly suitable for perimeter applications.
The Air2-QDT600W detector is certified to grade 2 according to EN50131-2-4 and EN50131-5-3 standards.
Air2-QDT600W detector features | |
Communication with Air2-BS200 transceiver |
Two-way |
Digital signal analysis |
Yes |
Coverage range |
3 m |
Security rating |
2 |
Protections |
Anti-opening, anti-tilt, anti-masking |
Motion direction detection |
Yes |
Temperature compensation |
Yes |
Bypassable signalling LED |
Yes |
Pulse counter |
Yes |
Sensitivity adjustment |
Yes |
Microwave frequency |
24.0 - 24.25 GHz |
Battery |
CR17450 |
Estimated battery life |
3 years |
Dimensions (HxWxD) |
138x35x32 mm |
Weight |
84 g |
Air2-QDT600W/B: wireless dual technology curtain detector with anti-masking function. Colour White.
Air2-QDT600W/M: wireless dual technology curtain detector with anti-masking function. Colour Brown.
Air2-QDT600W - Asennus- ja ohjelmointioppaasta (Finnish) (File PDF - 469 Kb)
