SmartLan/SI
Ethernet interface for connections to the Internet via TCP/IP protocol, provides SIA-IP protocol digital communicator
For those who do not require particularly advanced remote control capabilities but are interested in providing the SmartLiving control panel of simple connectivity features, INIM also offers a basic version of SmartLAN, the SmartLAN/SI.
This optional board makes available the remote programming and supervision functions from the local network and the Internet (using the SmartLeague and SmartLook softwares), the digital communicator toward the alarm receiving centres with SIA-IP protocol, the remote access via the AlienMobile app.
The use of SmartLAN/SI provides full access to Inim Cloud services.
Main features | |
SmartLAN/SI |
|
Plug-in mounting to motherboard |
Yes |
Encrypted data |
Proprietor |
Connection to LAN Ethernet 10-100 Base T |
Yes |
System programming and control over IP using SmartLeague software |
Yes |
Static IP address management |
Yes |
Dynamic DNS management |
- |
Multi-connection management |
- |
Inim Cloud Connectivity |
Yes |
SIA-IP protocol digital communicator |
Yes |
Sends e-mails with attached files |
- |
SD card connector |
- |
Attached files saved to SD card (not included) |
- |
Manages SD card memory |
- |
|
Web server functions for PCs, Tablets and Smartphones:
|
- |
Manages AlienMobile App |
Yes |
Dimensions (HxWxD) |
54x81x30mm |
Weight |
45g |
SMARTLAN-G/SMARTLAN-SI - Data sheet (File PDF - 432 Kb)
